Pulp Molding Egg Box Forming Machine 100KW Waste Paper Recycling

Name: Pulp Molding Egg Box Forming Machine 100KW Waste Paper Recycling
Brand: ZH brand
Price: 1 USD

China Pulp Molding Egg Box Forming Machine 100KW Waste Paper Recycling wholesale

Place of Origin : Hunan, China

Brand Name : ZH brand

Model Number : E4000B

Certification : ce

Packaging Details : Waste Paper Recycling Machine to produce egg tray dish 4000 pecs per hour export packing

Supply Ability : 200 Set/Sets per Year Waste Paper Recycling Machine to produce egg tray dish 4000 pecs

Price : Negotiation

MOQ : 1set

Delivery Time : 60-90days

Payment Terms : L/C, T/T, D/A, D/P

Condition : New

Product Type : Egg Tray Machine

Processing Type : Pulp Molding Machine, Pulp Molding Machine

Voltage : 380-440V

Power : 100KW

Dimension(L*W*H) : 21X2.12X4.2M

Weight : 30t

Warranty : 12 months

After-sales Service Provided : Engineers available to service machinery overseas

Name : Waste Paper Recycling Machine to produce egg tray dish

Production : Egg Tray, Fruit Tray, Cup Carrier, Disposable Medical Care Products

Automation : Fully Automatic

Capacity : 4000 PCS/hour

Dryer : 6 Layers

Raw material : Waste Paper

Finished Products : Egg Tray Egg Carton

Port : Guangzhou

Contact Now

Waste Paper Recycling Machine to produce egg tray dish 4000 pecs per hour

4000

E4000B (full auto, Rotary, 6 layers drying line) specification list

Type of products	30-cell egg tray	12-cell egg carton/box	10-cell egg carton/box	6+6- cell egg carton/box	6-cell egg carton/box	Fruit tray	Coffee tray
capacity (PCS/HR)	4000	4000	4000	4000	8000	3000	5000

Remarks: The capacity calculation takes the production of 30 cavity egg trays as the standard.(Size 300X290MM, weight 70g)

The Power list (Auto 4000B1C)
NAME AND TYPE			QUANTITY	POWER (KW)	REMAKR
Pulping System	1	SY-100-710 Conveyor	1	3
	2	ZSJD-3 Hydrapulper	1	55
	3	ZSK-1.8 Vibration Screen	1	4
	4	JB-160-210 Agitator	2	6	3kw/set
	5	Stock Pump	2	8	4KW/SET
	6	Water Pump 1	1	5.5
	7	Water Pump 2	1	2.2
	8	Water Pump 5	1	4
Forming System	9	XZ8-14040 Automatic Rotary Forming Machine	1	11
	10	Filter	1	0.37
	11	Water-ring Vaccum Pump	1	75
	12	Air Compressor	1	30
	13	Refrigerated Air Dryer	1	2
Drying Systerm	14	Drying Line	1	32.2
Stacking System	15	Finished Product Conveyor	1	0
Stacking System	16	Stacker	1	0
Total Power				238.27

Consumption List (Auto 4000B1C)
NO.	DESCRIPTION	CONSUMPTION PER HOUR	REMARK
1	Waste Paper	300kg
2	Electricity	180kw
3	Water	1.5-2.5T
4	0# Diesel Oil	40-45kg	choose anyone from the three
	Natural Gas	45-55m³
	LPG	35-45kg
5	Chemical for Water Resistence	1.5-2.0kg	Solid Content This data only for reference
The Calarific Value of the Fuel	10000K CARL/ kg for Diesel Oil		Energy Consumption of No.4 is counted with these data.
	8000K CARL/m³ for Natural Gas
	10000k CARL/ kg for LPG

Pulp Molding Egg Box Forming Machine 100KW Waste Paper Recycling
